General
Manufacturer TMT GLOBAL
Model TMT Global TMT-7401
Manufacturer Part No 6X136BLB
Compatible Country Middle East, Africa, Iran, Dubai
Country of Origin UAE
Price AED 205

TMT Global TMT-7401 Cat6 23awg 4 twisted pair Network Cable 305m LSZH Blue


• Conductor: Bare Copper
• Conductor Size: 23AWG
• No. Of Pairs: 4 twisted pairs
• Overall Coverage: N/L
• Outer Jacket: LSZH
• Jacket Color: Blue/Black/Grey/Violet/Orange
• Packing: 305m / Box
  • AED 205

  • Inclusive of VAT
  • or 4 payments of AED 51.25 No interest, no fees. Learn more
  •   *Get it in 1-3 hours   terrabyt-express

Are you wholesaler or reseller?

QuantityPrice
10+AED 100
25+AED 100
50+AED 100
  • Fulfilled by Terrabyt
  •  Condition: New
  •    Deliver To UAE
    Delivered by Tomorrow, Nov 02
    If you order within 6 Hours, 19 Minutes

TMT Global cat6 23awg 4 twisted pair Network Cable 305m LSZH are Manufactured Tested and Complied with IEC 60332-1-2 EN 50173-1:2011 ISO/IEC11801:2011(Ed. 2.2) ANSI/TIA/EIA-568.2-D IEC61935-2:2010(Ed.3.0) EN 50173-2:2007 including Amendment A1:2010 Requirements for Patch Cord Assemblies and Provide High Performance levels for structured cabling systems.

APPLICATION
10BASE-T, 100BASE-TX Fast Ethernet,
1000BASE-T (IEEE802.3
100VG-AnyLAN (IEEE802.12)
550 MHz Broadband Video
Voice, T1, ISDN
155/ 622 Mbps ATM
Power over Ethernet (POE)

GENERAL SPECIFICATION
4 Pairs UnShielded Twisted Pair (UTP) Cable
Gold Plated: 30U”
Color Code: Aqua/Black/Blue/green/Grey/Orange/Red/Violet/White/Yellow r custom color
Length : 0.12/0.15/0.50/1/2/3/5/8/10/15/20/25/30/40/50/70/100/meter r custom Length
Contact blade: Phosphor Bronze
Insulation Material: HD-PE-PVC-LSZH
Jacket Material: PVC UL94V-0

PHYSICAL AND MECHANICAL PROPERTIES
Conductor Resistance: ≤5Ω – ≤20Ω
Insulation Resistance: ≥10MΩ
Characteristic Impedance: 100 ― 6 Ohm @ 1-250MHz -1-500 MHz
Contact Resistance: 20 m Ohm max
Resistance Unbalance: 2% max
Dielectric strength: 1000 volts/1 minute min rms
Cable to Plug Tensile Strength: 9 Kgf (90N) min
Durability: 750
Temperature Operating Range: -25°C to 70°C


Download TMT Global TMT-7401 Datasheet

show more
General
Manufacturer TMT GLOBAL
Model TMT Global TMT-7401
Manufacturer Part No 6X136BLB
Compatible Country Middle East, Africa, Iran, Dubai
Country of Origin UAE
Price AED 205
